LF-20N LED Power Driver ( LED Power Supply )

LF 20W Surge Protection Constant Dimmable Current LED Power Supply for Street Lighting

  • Constant current mode
  • Isolated power supply with plastic case
  • Build in protection function of short circuit, over current, over voltage and over temperature
Category:

Item: LF-20N
Power: 20W
Application: Flood light, Stage light, Street light and Area light
Certificates: UL ClassP, TUV, CCC, CE
5 Years Warranty

Features of 20W Surge Protection Constant Dimmable Current LED Power Supply

Efficiency up to 86%
IP65
Protections: SCP/OCP/OVP/OTP
Surge Protection: L-N: 2kV
Operation temperature: -40~+60





Model AC Input Range DC Output Range Output Current Output Power
LF-20N023 (100-240)Vac (11-23)Vdc 0.6-1A 20W
LF-20N042 (100-240)Vac (24-42)Vdc 0.3-0.6A 20W
LF-20N054 (100-240)Vac (42-54)Vdc 0.2-0.5A 20W
