LG-20MA LED Power Driver ( LED Power Supply )

LG-A 20W UL TUV CCC CE Dimmable Constant Current LED Driver with SCP OCP OVP OTP

  • Constant current mode
  • Isolated power supply with plastic case
  • Build in protection function of short circuit, over current, over voltage and over temperature
  • With 1-10v dimming function
  • Build-in 3-in-1, intelligent time isolated dimming function ( dim off or not )
  • With auxilliary power +12V ( optional )
Category:

Item: LG-20MA
Power: 20W
Application: Flood light, Stage light and Area light
Certificates: UL ClassP, TUV, CCC, CE
5 Years Warranty

Features of 20W UL TUV CCC CE Dimmable Constant Current LED Driver

Efficiency up to 86%
Isolated Dimming (Optional): 0-10V, PWM, Resistor
IP65
Protections: SCP/OCP/OVP/OTP
Surge Protection: L-N: 2kV
Operation temperature: -40~+60



Model AC Input Range DC Output Range Output Current Output Power
LG-20M023A (100-277)Vac (11-23)Vdc (0.6-1)A 20W
LG-20M042A (100-277)Vac (24-42)Vdc (0.35-0.6)A 20W
LG-20M054A (100-277)Vac (33-54)Vdc (0.25-0.4)A 20W
